SUPERSYSTEM integral collection

Multi-functional LED lighting tool

SUPERSYSTEM integral collection

Seamless and linear

Design: EOOS

SUPERSYSTEM integral Synchro Gimbal and LED maxi Spotlight
3-phase track | channel | pendant

“The comprehensive planning tool is based on the poetic idea of stringently miniaturising the spotlight heads, enabling them to be perfectly integrated into a continuous linear structure. The system magically emits light from a slender groove as a recessed or track fitting. SUPERSYSTEM integral even makes it possible to adapt existing track installations, which improves efficiency and saves resources – and helps this system make an important contribution as a sustainable design solution.”

Harald Gründl, EOOS

SUPERSYSTEM integral collection

Nomen est omen

Integral. Because variety integrates perfectly into architecture.


The defining feature of the entire product group is seamless linearity – regardless of whether SUPERSYSTEM is used integrally as a single luminaire or installed on a track. Surface-mounted, built-in or pendant. Even with a channel, if required. And for the first time, this solution can be used for all types of lighting, from horizontal to vertical, from indirect to accent lighting.

SUPERSYSTEM integral collection

BSP

SUPERSYSTEM integral collection

Because the lighting is quickly modernised.

With a channel cover

For a closed lighting solution that is reduced to an ­absolute minimum, both the new luminaires and the channel cover are simply clicked on.
On a line with the 3-phase track

All the luminaires in the SUPERSYSTEM integral collection and even the adapters of the SUPERSYSTEM spots form a continuous line. If desired, the gaps can be closed with a blind cover.
A track is still as good today as it has always been. That is why it is now being reused to modernise lighting with the help of SUPERSYSTEM.

SUPERSYSTEM integral collection

Because everything fits together perfectly.

1 Copper base reflector
2 Device box with lock
3 Synchro Gimbal function
4 Aluminium-sputtered base reflector
Each individual luminaire fits the dimensions of the track. Fixed, rotatable and pivotable – the difference is hardly visible on the outside. Even the wallwasher blends discreetly into the system. High- quality surfaces complete the minimalist look, which nevertheless offers a high degree of personalisation. Luminaires and base reflectors can be combined in any colour.

Luminaire and cover: Black, White
Base reflector: Black, White, Aluminium-sputtered, Copper

SUPERSYSTEM integral collection

Product overview

The new gimbal accent lighting

For a long time it seemed impossible to create a rotating cone of light with a linear luminaire. Now SUPERSYSTEM integral shows how it can be done, as synchronously tiltable reflectors and a pivotable light head rise to the challenge. The cones of light are homogeneous, are available in different beam angles and can be moved in all directions. This is precisely alignable accent lighting that always looks linear.

Downlights with added value

The light heads can be moved on the track in both directions by 90 degrees. They can also be moved 25 degrees in both directions in the channel. This allows recessed luminaires to fulfil a wide variety of lighting tasks. SUPERSYSTEM integral rounds off this flexible type of vertical and horizontal surface lighting with a high level of brilliance and outstanding glare control.

Direct-indirect solution with pendant and channel

Direct and indirect luminaires in the H track simultaneously fulfil ­essential lighting tasks and create a cosy ambience. Homogeneously ­illuminated ceilings are thereby able to exploit all the possibilities of ­direct lighting. With total linearity. Power for all luminaires is provided via the 3-phase track, which also transmits control commands for ­individual lighting scenarios.

Variety with a linear design language

SUPERSYSTEM integral offers lighting designers plenty of scope for ­illuminating horizontal surfaces. Various lumen packages, lighting ­angles and colour constellations help establish this compact downlight as a highly ­adaptable lighting tool. Even safety lighting can be almost invisibly integrated thanks to the emergency lighting option. With low ­luminance levels and a high level of visual comfort, the SUPERSYSTEM ­integral collection is also ideal for use in foyers, access zones and office spaces.

Wallwashing without light scatter

The miniaturised version of the liteCarve® free-form reflector now makes it possible. This solution emits 100 percent of the light directly, purposefully and evenly onto the vertical surface – with no glare and no light scatter on the front wall or ceiling. The integration of the design is just as sophisticated. The wallwasher fits precisely into the lines of the SUPERSYSTEM integral collection – both on the track and as a stand-alone version.

Gimbal accent lighting
Pivotable light head
Indirect lighting
Built-in downlight
Wallwasher

SUPERSYSTEM integral collection
