In the “Lighting Handbook”, practicians will find everything worth knowing about lighting technology and lighting applications. In addition, the Zumtobel Lighting Handbook includes reference values as well as information on lighting control, control gear and emergency lighting, thus facilitating project design.

» Click here to download the Lighting Handbook..

The printed version is available from your » nearest Zumtobel contact.

Zumtobel. The Light.

This autumn we have again numerous highlights to introduce: from the LIGHT FIELDS evolution LED luminaire range, the ARCOS xpert LED spotlight and the ARCOS LED wallwasher through to moisture-proof LED luminaires and the SINUS medical supply unit.

You will find an overview of all highlights on our website and in the pdf brochure. For each highlight, a picture of the product together with a concise summary of the product details is available. Further details regarding individual products can be obtained from the links provided.

» Click here to go to the autumn 2013 Highlights on our website.

» Click here to download the Highlights pdf brochure.

Zumtobel. The Light.

The updated version of the ONLITE Resclite iOS app has been optimised for iPad, but allows for quick and easy emergency lighting design on the iPhone 5 as well. The mounting height is set with just one finger swipe, and the maximum spacings between two luminaires are then displayed immediately.

The most recent version of the easy-to-use design program for electricians and electrical consultants now also includes the new RESCLITE high ceilings model: a unique emergency luminaire on the market, which can be used in rooms with ceilings of 7 m to 30 m height (30 m RESCLITE antipanic; 23 RESCLITE escape) and is therefore perfect for applications such as DIY markets, warehouses and industrial bays.

The RESCLITE luminaires have also been fitted with a new, more efficient LED and optimised lenses. The spacings between luminaires, which have consequently been increased, have been updated in the app. Increased spacings means that in order to reach lux levels in conformity with applicable standards, fewer luminaires are needed and costs are therefore reduced.

The new NPS type of supply, which is a cost-effective, centrally supplied alternative, with optional circuit monitoring but without monitoring of individual luminaires, has been integrated in the app.

» Click here to download the updated ONLITE Resclite app free of charge

Zumtobel. The Light.

In order to create a custom product variant, simply select the product range required on our website. Then go to the configurator, e.g. “myIYON” for the IYON product range, and from a variety of additional functions choose the options that suit your project requirements best.

You can then forward the options you have chosen directly to our sales staff, who will be pleased to send you a quotation and answer any questions you may have.

The following example (in English) based on the IYON LED spotlight demonstrates how easy it is to create your custom luminaire using myPRODUCT.

Zumtobel. The Light.

Attended by over 750 leading names in the lighting world, the Lighting Design Awards are among the biggest and most prestigious architectural lighting competitions in the world.

This new Social Marketing concept lets employees set the agenda in social media, using a basket of channels to show their professional knowledge and specific experience and to tell the world their Zumtobel story.

These stories cover the core principles of the Zumtobel brand – knowledge, design, innovation and projects – and support our objective to create the best light for people and the environment.

Zumtobel are realising their Social Marketing concept through a combination of established social media channels and a high quality international blog and content curation site at » www.lightlive.com.

This innovative site collects and promotes applied lighting knowledge, bringing together relevant and informative social media content from Zumtobel and trusted third parties.

Users can read the latest blog entries, post comments, watch videos and find out about Zumtobel activities on the individual social media channels.

A comprehensive hashtag concept enables lightlive users to quickly and easily find content on specific topics by simply clicking on the relevant hashtag.

» www.lightlive.com
» Twitter: @Zumtobel_Light
» LinkedIn
» Vimeo
» Youtube
» Google+

Zumtobel. The Light.

The objective of the global study is to have the lighting quality in offices evaluated by you, the users.

Your answers will make a valuable contribution. Based on the findings of this study, it will be possible for the very first time to define lighting quality in offices with a focus on users, beyond conformity with relevant standards.

The survey will not take more than 10 minutes to complete.

» Click here to go to the survey.

For each completed questionnaire, Zumtobel will donate € 3 to the » Light for the World charity. We would appreciate if you forward the link to the questionnaire to your friends and acquaintances. Every feedback will count!

Zumtobel. The Light.

The drag & drop link marked by the icon can be found in the online catalogue product information for each article, next to the drag & drop links for export to Dialux and Relux. You can either click the link or drag it to the ecoCALC calculation program in order to import luminaire and component data. More than 16,000 products, luminaires and components are available in the online catalogue in this manner.

As manual luminaire definition is no longer required for all luminaires and components included in Zumtobel's current online catalogue, analysing lighting solutions becomes more efficient, easier and less prone to errors. Of course, luminaires can still be defined manually.


In addition to the luminaire's technical data relevant for economic efficiency calculation, such as installed load, lamp type with maintenance characteristics, dimming behaviour or maintenance type, also product images, descriptive text and article numbers are transferred, so that the results of the calculation will become easier to understand and to check.

ecoCALC's advantage is that it allows analysis not only of individual luminaires, but also of entire lighting solutions, independent of manufacturer and time of construction. Both energy consumption and all costs associated with operating a lighting solution are taken into account.

Other practical functions of ecoCALC you may not yet know about:
•    Flexibly adjustable presentation diagrams with improved layout
•    Solution and product images can be added
•    Additional product-specific information such as article number or product description can be displayed
•    Analysis of complex operating scenarios using a variety of lighting scenes or types of use in an extended mode
•    Additional mode for analysing outdoor lighting
•    ecoCALC is fully compatible with Windows 8 and all Windows operating systems from Windows XP


A few more things you should know: ecoCalc...
•    ....features a wizard mode and extensive contextual help for your convenience.
•    …supports you in optimising your maintenance cycles and the associated costs.
•    …analyses whether the required illuminance levels will be maintained over the entire course of the lighting solution's service life and also provides a graphic representation of the results.
•    ….has so far been downloaded by several thousands of customers.
•    …contains some 2000 data sets including lamp and control gear characteristics

Download the latest version of ecoCALC and benefit from the new functions: » http://www.zumtobel.com/ecocalc

Zumtobel. The Light.

Zumtobel showcased some of their latest innovations in LED technology at the Energy Efficiency Exhibitions incorporating the Renewables Roadshow. Taking place at 6 different venues across the UK including; Westpoint Area, Exeter on 10th September, Ricoh Arena, Coventry on 12th September, Metro Area, Newcastle on 17th September, The Royal Highland Centre, Edinburgh on 19th September, Sandown Park, Surrey and Event City, Manchester on 26th September, the show attracted quite a crowd with in excess of 4500 visitors.

Located on stand number 56, Zumtobel were also invited to and gave a, top class talk and presentation entitled 'Use less energy, getting better lighting quality.....'

Zumtobel will next be exhibiting at the renowned Light & Building Exhibition in Frankfurt which takes place from 30th March - 4th April 2014, come visit us....

Zumtobel - The Light. - Come and be inspired............

This is the fourth year that the Zumtobel Group calls for submissions for its 2014 architectural award to enhance quality of life and sustainability in the built environment – the ZUMTOBEL GROUP AWARD – INNOVATIONS FOR SUSTAINABILITY AND HUMANITY IN THE BUILT ENVIRONMENT.

From 1 September until 30 November 2013, architecture firms and engineering studios, urban planners and landscape architects, universities and recently established technology companies, NGOs as well as public and private initiatives can submit their current projects.

Three categories
The ZUMTOBEL GROUP AWARD is awarded in the following three categories, each presented by one of the international lighting group's three brands:

• Buildings
• Urban developments & initiatives
• Applied innovations

“Buildings” category by Zumtobel
In the “Buildings” category presented by the Zumtobel brand, outstanding building projects that have been completed within the last two years (from 30 November 2011 to 30 November 2013) can be submitted. This category includes both new buildings and refurbishing projects. The award-winning project should meet the highest aesthetic demands and also involve innovative solutions for optimised use of resources, environmental protection and the improvement of living conditions. The jury will place a special focus on the application of cutting-edge technologies.

Curators and awarding of prizes
As in the previous years, the Zumtobel Group Award 2014 will be curated by Kristin Feireiss and Hans-Jürgen Commerell of Aedes Architekturforum in Berlin. From all the projects submitted, a preliminary jury will select 14 projects per category. The main jury consisting of internationally renowned experts from various disciplines will nominate five projects per category early in summer 2014 and will choose from them one award-winner in each category. The prize award ceremony will take place in autumn 2014.

For further information on the ZUMTOBEL GROUP AWARD, please refer to
» http://www.zumtobel-group-award.com

Zumtobel. The Light.

18 active and 16 observer countries will in future be responsible for standardisation in the field of applied lighting technology at global level. The aim is to specify global standards for internationally operating companies and organisations using consistent terminology, methods of calculation and procedures in order to facilitate international consulting and understanding.

For Zumtobel, being part of London 2012 meant putting fantastic lighting concepts into practice and creating luminous art works. The realisation of future lighting visions with state-of-the-art LED technology created a unique design experience on the occasion of London 2012. Zumtobel supplied products for the following areas; Olympic Stadium, Aquatics Centre,Velodrome, Copper Box, Lee Valley White Water Centre, Olympic and Paralympic Village, Administrative & Security Centre, Chobham Academy, Stratford International Station, Olympic Greenway, Energy Centre, Eton Manor, ArcelorMittal Orbit Visitor Centre and the Run Sculpture.

The sustainability vision “Through light, we care.” is the basis of all business processes of Zumtobel and the other two brands within the Zumtobel Group – Tridonic and Thorn.

One example from the current sustainability report: in the 2012/13 financial year, the Zumtobel plant in Dornbirn carried out analyses of its material flow cycles. By increasing the efficiency of resources and materials used and creating sustainable cycles, potential energy savings of EUR 1 million have been opened up at this plant alone.

In addition to this example, the current report also contains detailed information on the challenges faced as well as the sustainability strategy and the targets achieved in the year under report. Among other things, the report addresses in detail the spheres of quality management, research and development, production and supply chain as well as social commitment.

75% of all industrial and office lighting in Europe is obsolescent or inefficient
The report also presents examplary projects and products as well as interesting facts: for instance, 75% of all industrial and office lighting in Europe is obsolescent or inefficient even today.

The report was published in German and English and takes its lead from the recognised Guidelines of the Global Reporting Initiative (GRI G3.1). This allows for transparency and makes it possible to compare companies' sustainability achievements.

Click here to download the Magazine section of the sustainability report.
» In English
» In German

Click here to download the Facts section:
» In English
» In German

Zumtobel. The Light.

Fingers at the Ready.....

As Europe's leading lighting manufacturer, how light works is very important to us. By using your imagination and making the most of the summer and early autumn light, you could win a great prize!

Since its inception in 1997 we have had in excess of 8500 architects taking part in The Zumtobel Photographic Competition, last year was no exception with over 1250 camera requests (see images for some of last year's winners).

Every year we mail out in excess of 1000 disposable cameras to leading architects all over the UK. Participants are required to capture images that will excite and stimulate our esteemed panel of judges. There is no set topic so you have the ability to photograph anything you wish, the choice of topic is endless! The images could involve internal or external architectural details, shots of people, still life, structures in the news taken from an obscure angle - or purely abstract. We are specifically looking for the best use of light captivated in the shot.

On 7 June 2013, the winner of the Mies van der Rohe award was presented in Barcelona. The EUR 60,000 award dedicated to contemporary architecture is granted every two years by the EU Commission and the Mies van der Rohe Foundation. This year, the award was given to the Harpa concert hall and conference centre in Reykjavik, which is illuminated by a Zumtobel lighting solution.

Revitalised harbour
Since August 2011, congresses, conferences, concerts have been held at “Harpa”, which is also the residence of the Icelandic Opera and the Iceland Symphony Orchestra. This makes the building, which incorporates a 1800-seat concert hall and three smaller halls, a cultural highlight also on an international level. One of the reasons the jurors gave for honouring this project was that the building helped revitalise the harbour by providing a better connection to the city.

The seamless interplay of local and global influences is also reflected by the designers involved: basically, Henning Larsen Architects and Batteríið Architects from Denmark and Iceland, respectively, and acoustics designers from the New-York-based firm Artec Consultants.

Lighting art and artificial lighting
Of particular importance for the project was, however, Danish-Icelandic artist Ólafur Elíasson, who created the design for the building's unique glass shell and its illumination, which was implemented in collaboration with Zumtobel, his long-standing expert partner when it comes to lighting solutions. His lighting concept was based on the desire to set the stage for light as a transcendent event where the source of light remains invisible.

In collaboration with Ólafur Eliasson, Zumtobel developed a new type of luminaire which, thanks to its design and colour, can be integrated nearly invisibly into the façade's prismatic structure, illuminating it with LEDs.

Five finalists
“Harpa” came out victorious against the four other finalists: Metropol Parasol in Sevilla, the Ghent Town Hall, Superkilen in Copenhagen and a senior citizens' home in Portugal. The “Emerging Architect Special Mention” prize was awarded to María Langarita and Víctor Navarro for the Nave de Música Matadero (Red Bull Music Academy) in Madrid.

» Click here to see more details and pictures of this project

Zumtobel. The Light.

Held on 26th April 2013 at Quaglinos Restaurant in London's Mayfair, the Top 21 achievers in the 2012 Zumtobel Photographic Competition attended a special lunch held in their honour.

Our Top 21 extremely talented and budding photographers, were selected from over 1300 architect entries that we received in 2012. Well done to them all!

The Top 21 were presented with their winning photographs enlarged and framed with the Top 4 achievers receiving some state-of-the-art photographic equipment. A fabulous afternoon was had by all.

Thanks again to our 21 for taking part and to our judges for helping us to select such great and worthy winners.

The Zumtobel Photographic Competition takes place each and every summer. So, if you are a UK based architect and fancy trying your photographic skills in an excitng competition, then please get in touch via e-mail [email protected] or contact the Photographic Competiton Hotline 01753 482 662. You have the ability to photograph anything you wish and could win some fantastic photographic equipment!

We look forward to receiving your entries!

Congratulations to the winners of the 2012 Zumtobel Photographic Competition, check out our video below to see who the lucky winners are!

A huge thank you to all those that took part in the 2012 competition. It was yet another successful year for our popular competition, with in excess of 1250 camera requests!

The standard of photography was, as always, extremely high giving the judges a difficult task to select the Top 21 entrants. The judges for 2012 comprised of; Steve Shackleton - Marketing Director for Zumtobel Lighting, Andy Cassie - Managing Director for CIB, Photographer Morley Von Sternberg, Francesca Gernone of Pringle Brandon Perkins + Will - Winner of the 2008 Zumtobel Photographic Competition and Azam Ashari of Barton Wilmore -Winner of the 2009 Zumtobel Photographic Competition.

The Top 21 entrants will attend a special lunch held in their honour on 26th April 2013 where the winners will be presented with some fabulous prizes.

We forward to receiving your entry and wish you the best of luck with the competition!

Two Zumtobel products have won the “red dot award: product design 2013”: the SFERA free-standing LED luminaire and the DISCUS Evolution LED spotlight system could not fail to impress the jury thanks to their outstanding product design. These innovative products are exemplary for successful design based on users' requirements.

SFERA
With the SFERA free-standing LED luminaire, Zumtobel sets new standards – especially with respect to adjustability and individual lighting quality. But SFERA's energy efficiency is impressive as well, thanks to a combination of the adaptive SENSCONTROL III lighting management system and the innovative SWARMCONTROL technology used for the first time in SFERA, which allows the configuration of the luminaires into a swarm without any additional software, providing for quick adjustment to altered room layouts.

Click here for more information:  » www.zumtobel.co.uk/sfera

DISCUS Evolution
The DISCUS Evolution LED spotlight system results from further development of an existing luminaire and cannot fail to impress on account of its perfectly matched light source and optic. The spotlight's flat design is now even more contemporary and minimalist. The delicate yet robust design of the spotlight created by the internationally renowned Vienna-based EOOS design studio was created for accent lighting and the sales-boosting presentation of goods.

Click here for more information: » www.zumtobel.co.uk/discus

This year, 1,865 manufacturers, designers and architects submitted a total of 4,662 products. The awards will be handed over and celebrated at the red dot gala at the Aalto Theater in Essen on 1 July 2013, in the presence of international guests, among them designers, business experts, politicians and media representatives. The prize-winning products will then be on display at the red dot design museum for four weeks.

Zumtobel. The Light.

LIGHTCENTRE - THE NEWS. brings you the latest information on our UK LightCentre, including, seminars and events we have taking place, new products lauched and the latest lighting technology and research. Our LightCentre is constantly evolving and aim is to keep you updated with all the latest developments, new things to see and experience.

We welcome your suggestions for LightCentre related topics you would like featured in future editions.

We hope you enjoy reading it and look forward to receiving your comments and suggestions. Click here or see the PDF below to view the Newsletter and find out more ............

To sign up to LIGHTCENTRE - THE NEWS. please e-mail your details to [email protected]

We look forward to hearing from you!

EPDs are product-specific environmental datasheets verified by independent testing institutes that document a product's environmental impact over its entire service life, resulting in enhanced product comparability.

Comparison between MELLOW LIGHT V LED (52 W) and MELLOW LIGHT V TC-L (55 W)
The example shown in the diagram illustrates the progress in product development. Although slightly more energy is required for manufacturing the LED model, it becomes apparent that the overall environmental impact of the LED luminaire – due to its reduced power consumption – is lower than that of the comparable luminaire featuring conventional lamp technology, if the utilisation period is taken into account.

Basis of calculation
Primary energy consumption* is calculated from the energy required for raw materials and their processing, transport by truck to the customer over a distance of 1500 km and a utilisation period of 15 years in a typical office application, based on the European energy mix.

Click here to view the EPDs of the two products:
» MELLOW LIGHT V LED
» MELLOW LIGHT V TC-L

* Primary energy consumption
The term primary energy is used in the power industry to denote the energy that is available using natural forms of energy or energy sources such as coal, gas or wind. In Europe, roughly 3.3 kWh of primary energy are needed to generate 1 kWh of electricity.

Zumtobel. The Light.

Held at our LightCentre in Chalfont St Peter our Symposium - 'A Light Less Ordinary' explores; 'Lighting for Humans' - The physiological, biological and psychological effects of daylight and artificial light, 'Lighting for Purity' - Minimising materials, degration, energy, guides and legislation. The technical factors, compliance and throughlife project performance and 'Lighting for Inspiration' - A space only becomes architecture with light. This includes, lighting for personality, vibrancy and materialisation.

Using our state-of-the-art Application Spaces (App Spaces) we will take you on a journey through light, beyond visibility and visual company to show what a difference light can make to a space.

With our passion for light and a healthy helping of discussion and debate, we are sure that 'A Light Less Ordinary' will be an extremely valuable contribution to your knowledge base.

Suited to any professional or individual with a love of light, the symposium is fully 'CPD' accredited and worth 5 hours of accreditation.

Stephen Barty, Director of Ardler Ltd. attended the symposium in October 2012 and comments: "The visit exceeded my expectations. The new demo faclities were superb. Hospitality and seminars were excellent, as is normal for Zumtobel." Brian Rae, Technical Services Manager for Land Securities Overgate attended the symposium in October 2012 and comments "It was a well run professional presentation. The showroom was spectacular, products were leading edge and very impressive."

To find our more and to book a place on 'A Light Less Ordinary' Symposium please e-mail [email protected] or telephone 01753 482 662.

We look forward to hearing from you...

In times of technological, economic and social changes, our living and working spaces are permanently changing. Zumtobel has therefore identified the need for a new quality of light and produced a new video focussing on the company's vision to provide perfect light for people and the environment.

It impressively demonstrates Zumtobel's application know-how based on the leading actor's daily routine.

» Watch the video and see for yourself!

Zumtobel. The Light.

DIMLITE, a simple lighting control system for individual rooms, was developed to facilitate the first step into lighting management, providing core functions such as dimming, lighting scenes, presence-based and daylight-based lighting management.

The free Zumtobel DIMLITE iPad app quickly provides answers to questions such as:
•    How do I meet the room user's lighting demands?
•    Which control unit is appropriate for my purpose?
•    How do I connect the individual components?

As a result, the DIMLITE app produces a pdf file that includes the schematic circuit diagram and a parts list. Only a few steps are necessary to obtain this file:

1.    Select the number of luminaire groups, luminaires per group and control signal (DALI or DSI).

2.    Specify whether the component is to be installed in a switch cabinet or recessed into the ceiling (depends on the number of luminaire groups).

3.    Is daylight-based lighting management required?

4.    Design of schematic circuit diagram based on possible functions.

The app also includes practical guidelines providing information on the functions and commissioning of DIMLITE, together with examples of how and why to use DIMLITE. The app is available in German, English, French, Italian, Dutch and Spanish.

» Click here to download the app
